General Specifications
| EV charger type | AC |
| Wireless communication | Wi-Fi 2,4 GHz (IEEE 802.11b/g/n) |
| Interface protocol | OCPP 1.6] / 2.0 HW Ready |
| Protections | 6 mADC leakage detection |
| Enclosure rating | 1P65 / IK10* |
| Enclosure material | ASA/PC |
| Operating Temperature | -25 °C to +60 °C |
| Ambient temperature storage | -40 °C to +70 °C |
| Operating humidity | 5% to 95% Non-condensing |
| Light beacon | LED colour indicator |
| Power limit control | Mode 3 PWM control according to IEC 61851-1 |
| RFID reader | ISO/CEI 14443 AB FéliCa ISO/CEI 15693 ISO/CEI 18092 |
| Flame retardant grade | UL94V-0 |
| Display | 3,5” colour screen |
| Dimensions (P x L x H) | 90 x 210 x 305 mm |
| Weight | 3kg |
| Safety protection | Welded contactor detection |
Model Specifications
| Model | EV32DWRS | EV32DWRT |
|---|---|---|
| AC power supply | 1P+N+PE | 3P+N+PE |
| AC input voltage | 230 VAC +/-20% | 400 VAC +/-20% |
| Maximum input current | 32A | 32A |
| Maximum input power | 7,4KW | 22kW |
| Number of outputs | 1 | 1 |
| Maximum output power per outlet | 7AKW | 22kW |
| Maximum output current per outlet | 32A | 32A |
| AC output voltage | 230 VAC (1P + N + PE) | 400 VAC (3P + N + PE) |
| Plug Type (cable length 3 meters) | 1 x Type 2 Plug (locking system) | 1 x Type 2 Plug (locking system) |
